Moving Coil Cartridges

SkyAnalog initially started designing tube amplifiers, much later they started designing High-End MC pickups. The G-series has, among other things, a unique aluminum body and a cantilever of Borium, Ruby or Sapphire.

Skyanalog P1M capsule has a black aluminum housing, in which an Al stylus MC type motor with a Fineline diamond stylus profile has been installed. The collection needle has a 5x50um grind. The needle axis was placed at an angle of 20 degrees to the end of the bobbin body. The manufacturer recommends the 8.9g pill for light heavy arms, with an effective weight of 11-14g. The output voltage is 0.4 mV at a rate of 3.54 vm/s. The internal resistance of the pure copper crossover winding is 6.5 ohms, which should be terminated between 100 and 220 ohms per manufacturer’s recommendations. The pickup’s frequency response is accurate to +/-1dB between 20Hz and 20Khz, while channel separation is better than 30dB at 1Khz and channel balance is better than 0.5dB, which is an excellent value. The recommended needle pressure is 1.6 to 2.0 g, the recommended optimal value is 1.8 g.
